Polygon Heist X5

Color	Cream
Size	S M L XL Clear

Color

Size

REACH WIDER - YOUR ALL-DAY CHOICE FOR ALL-URBAN TERRAINS

The Polygon Heist X5 is here - with its 1x Groupset you can shift easier; the reliable hydraulic disc brakes provide you a powerful stopping in any condition and easier maintenance; and take you wherever you’re heading to faster than before with its low rolling resistance tire. As you cruise farther, Heist X is here to bring you the best riding feels ever.

Easier shift, better experience

There’s more in less. The biggest advantage from a 1x drivetrain is it lets you focus on your ride, instead of constantly adjusting gears. Now you can have more and better experience on trails.

Get faster on trails

Accompanied with low rolling resistance tires to reduce the energy loss as a tire rolls, decreasing the required rolling effort. Enabling you to get wherever you’re heading to faster than before.

Rough conditions wont stop us

With it’s suspension fork to smooth out the ride. and Hydraulic disc brakes that let’s you experience a smooth and powerful braking performance; there’s no condition that can stop you to explore more

AL6 URBAN CROSS 700C ALUMINUM FRAME. Light & durable hydroformed 6061 Aluminum frame with internal cable routing and rear thru axle for extra stiffness.

SHIMANO DEORE M6000 1X10 SPEED DRIVETRAIN. Simplicity of single chainring combined with smooth and effortless shifting operation.

SUNTOUR NVX FORK. Provides 63mm of travel for extra comfort, hydraulic lockout.

SHIMANO MT201 HYDRAULIC DISC BRAKES. Proven, bombproof design with reliable braking performance.

WTB RIDDLER 700 X 45C TIRES. Predictable, fast, grip in every situation.

Polygon Heist X5 is a durable urban bike providing a comfort city riding with mountain bike durability for light off-road adventures. Urban bike with MTB soul – this bike is one of the best solution for any urban warrior looking for a durable commuting bike providing a comfort riding position & short fun weekend ride on their local single tracks

GEOMETRY & SIZE

SIZE CHART

Height/cm	150-160	160-170	170-180	180-190
Size	S	M	L	XL
Heist X	✔	✔	✔	✔

Weight	N/A
Dimensions	N/A
Color	Cream
Size	S, M, L, XL
Brand	POLYGON BIKES AND ACCESSORIES
Frame	AL6 URBAN CROSS, 12x142mm O.L.D. 2HRU
Fork	SUNTOUR NVX, PRELOAD ADJUSTER, HYDRAULIC LOCK OUT, STRAIGHT 1-1/8" THREADLESS
Head Set	INTEGRATED W/ SEALED BEARING FOR TAPER HEAD TUBE, IS 42/28.6, IS 52/40
Stem	ENTITY XPERT, EXT: 60mm (400, 431) / 80mm (470, 516), BAR BORE: 31.8mm, RISE/DROP: 7degree
Handlebar	ENTITY XPERT, EXT: 700mm, BAR BORE: 31.8mm, RISE/DROP: 0mm, BEND: 6degree
Rear Derailleur	SHIMANO DEORE RD-M6000/RD-M4120 DIRECT ATTACH
Shifter	SHIMANO DEORE SL-M6000/SL-M4100, 1X10 SPEED TRIGGER
Bottom Bracket	THREADED BB, BSA THREADED 68mm
Crank Set	PROWHEEL CHARM, 36T 2-PIECE-CRANK, MAX CHAINRING: 38T, CRANK ARM: 170mm (S, M) / 175mm (L, XL)
Cassette	SHIMANO CS-HG500, 10-SPEED 11-42T
Chain	KMC X10-1
Pedal	PP CAGE PEDAL W/ REFLECTOR
Brake	SHIMANO BR-MT201 HYDRAULIC DISC BRAKE, ROTOR: SHIMANO SM-RT26 160mm 6-BOLTS
Wheel Set	ALLOY DOUBLE WALL
Tire	WTB RIDDLER TIRE 700X45C
Saddle	ENTITY SADDLE, STEEL ø 7mm
Seat Post	ENTITY XPERT, DXL: 27.2X350mm, OFFSET: 15mm, SEAT CLAMP: 31.8mm W/ QR
Wheel Size	700
Frame Material	Aluminium (AL)
Weight	13.1 kg

Weight

N/A

Dimensions

N/A

Color

Cream

Size

S, M, L, XL

Brand

POLYGON BIKES AND ACCESSORIES

Frame

AL6 URBAN CROSS, 12x142mm O.L.D. 2HRU

Fork

SUNTOUR NVX, PRELOAD ADJUSTER, HYDRAULIC LOCK OUT, STRAIGHT 1-1/8" THREADLESS

Head Set

INTEGRATED W/ SEALED BEARING FOR TAPER HEAD TUBE, IS 42/28.6, IS 52/40

Stem

ENTITY XPERT, EXT: 60mm (400, 431) / 80mm (470, 516), BAR BORE: 31.8mm, RISE/DROP: 7degree

Handlebar

ENTITY XPERT, EXT: 700mm, BAR BORE: 31.8mm, RISE/DROP: 0mm, BEND: 6degree

Rear Derailleur

SHIMANO DEORE RD-M6000/RD-M4120 DIRECT ATTACH

Shifter

SHIMANO DEORE SL-M6000/SL-M4100, 1X10 SPEED TRIGGER

Bottom Bracket

THREADED BB, BSA THREADED 68mm

Crank Set

PROWHEEL CHARM, 36T 2-PIECE-CRANK, MAX CHAINRING: 38T, CRANK ARM: 170mm (S, M) / 175mm (L, XL)

Cassette

SHIMANO CS-HG500, 10-SPEED 11-42T

Chain

KMC X10-1

Pedal

PP CAGE PEDAL W/ REFLECTOR

Brake

SHIMANO BR-MT201 HYDRAULIC DISC BRAKE, ROTOR: SHIMANO SM-RT26 160mm 6-BOLTS

Wheel Set

ALLOY DOUBLE WALL

Tire

WTB RIDDLER TIRE 700X45C

Saddle

ENTITY SADDLE, STEEL ø 7mm

Seat Post

ENTITY XPERT, DXL: 27.2X350mm, OFFSET: 15mm, SEAT CLAMP: 31.8mm W/ QR

Wheel Size

700

Frame Material

Aluminium (AL)

Weight

13.1 kg
