With its sangria red colorway, the MXC 4 will cause some serious head-turning out on the trail. Built on our all-mountain carbon chassis with size-specific rear triangle, this rig boasts a super-progressive geometry, a slack, gnar-ready head angle, and mullet wheel set-up. Paired with the 160/140mm suspension travel, you’ve got a playful, agile, and, most-importantly, fun shred sled all tuned with some extra protective covers.

Gas Gas Mxc 4 12s Gx

Dialed motor

Like our other latest generation eMTBs, the MXC 4 is equipped with the state-of-the-art SRAM Eagle Powertrain drive unit featuring a 630Wh battery and AXS Bridge Display mounted in the top tube.

RockShox Suspension

This rig keeps things in the family with SRAM 4-piston DB8 brakes on 220/200mm rotors and 12-speed GX Eagle groupset. Suspension comes via a 160mm Lyrik Select+ fork and Deluxe Select+ shock.

Frameset

Frame29/27.5″, Carbon, Integrated battery, Boost, 140 mm
ForkRockShox Lyrik Select+, DebonAir+, Air, 160 mm, tapered
ShockRockShox Deluxe Select+, Air, 205×60 mm

Brakes & Drivetrain

MotorSRAM Eagle Powertrain Drive Unit, 250 W, 90 Nm
BatterySRAM Eagle Powertrain, 630 Wh
ChargerSRAM Eagle Powertrain Charger, 4 A
DisplaySRAM Eagle Powertrain AXS Bridge Display
Front brakeSRAM DB8, 4-piston, Hydraulic disc brake
Front brake rotorSRAM Centerline, 220 mm, 6-hole
Rear brakeSRAM DB8, 4-piston, Hydraulic disc brake
Rear brake rotorSRAM Centerline, 200 mm, 6-hole
Rear derailleurSRAM GX Eagle, 12-S
CassetteSRAM PG-1210, 11-50 T
ChainSRAM SX Eagle
ChainringSRAM XX Eagle Transmission
Crank armSRAM GX Eagle E-MTB
Shift leverSRAM SX Eagle, Single Click

Wheels

Front wheelRim: Mach 1 TRUCKY 30, With eyelets, No / Hub: GASGAS DA210F, 6-hole, 15×110 mm, thru axle
Rear wheelRim: Mach 1 TRUCKY 30, With eyelets, No / Hub: GASGAS DA210R, 6-hole, 12×148 mm, thru axle
TireMaxxis Assegai, 63-622, 29, 2.5
Rear tireMaxxis Minion DHR II, 62-584, 27.5 x 2.4

Cockpit

StemGASGAS 35, 0 °, Ahead
HeadsetAcros AZX-579 ZS56/ZS56
HandlebarGASGAS Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
GripsGASGAS MTB, Lock-on grips
SaddleSelle San Marco GND
Seat postGASGAS Pro, 34.9 mm, Dropper post

Accessories

PedalsGASGAS, aluminum
Chain guideDirect Mount

Additional Information

Weight23.3 kg
Permissible total weight130 kg
Trailer approvalNo trailer approval

Geometry

	M	L	XL
(A) Top Tube Length	588 mm	613 mm	638 mm
(B) Seat Tube Length	400 mm	440 mm	470 mm
(C) Seat Tube Angle	74 °	74 °	74 °
(D) Head Tube Length	120 mm	135 mm	150 mm
(E) Steering Angle	64.5 °	64.5 °	64.5 °
(F) Chain Stay Length	442 mm	445 mm	450 mm
(G) Wheel Base	1228 mm	1262 mm	1299 mm
(I) BB-Drop	31.5 mm	31.5 mm	31.5 mm
(L) Stack	644 mm	658 mm	671 mm
(M) Reach	445 mm	470 mm	495 mm
(N) Stem Length	40 mm	40 mm	40 mm
(O) Crank Length	165 mm	165 mm	165 mm

Color

Sangria Red/Blanca White

Size

S/M, M/L, L/XL

Wheel Size

27.5"

Brand

Gasgas
