Polygon Helios A8x

Brands: POLYGON
F. FRAME

Frame

ACX PERFORMANCE UCI APPROVED – Carbon

F. GROUPSET

Groupset

SHIMANO ULTEGRA Di2 2×12-SPEED

F. WHEELS

Wheels

ENTITY WR5 DISC (50mm) W/ TUBELESS TAPE – Carbon Wheels

F. USE

Use

From Daunting Air Drag to Coarse Road Surfaces

SKU: 395 Category: Tags: ,

Polygon Helios A8x

Brands: POLYGON

Buy more than AED 100 and get free delivery!
Black

Easy Return/Exchange

Fast Delivery

100% Secure Payment

Description

IN THE RELENTLESS PURSUIT OF SPEED

DESIGNED TO CUT THROUGH AIR BETTER

In our pursuit of speed, we cyclists have always seen nature as an adversary. From daunting air drag to coarse road surfaces, we sought to minimize interaction with our surroundings in hopes of achieving optimal efficiency. Helios is here to transform that paradigm because by embracing nature, we can be even faster.

Features

Cuts Through Air

The best teacher of aerodynamics comes from raindrops: the billions that seeks the most efficient way in cutting through air. With this inspiration, the new shape of Helios is designed to cut through air without leaving behind turbulence, thus achieving an industry-leading; 31% reduction in drag over previous generation designs.

Flies On Climbs

We went back to the basic philosophy of a bicycle: how do we leverage the rider’s work in the most efficient way possible? To this end, we reinforced the bottom bracket and right chainstay to instantaneously transmit pedaling power to the wheels. In addition, with one of the lightest frames at only 800 grams, it is designed to defy gravity and fly even in the most arduous of climbs.

Synchronized To The Human Body

At the end of the day, we designed Helios with its rider in mind. Few tracks are ever completely smooth or straight. The reinforcements, in conjunction with clearance for wider tires that is proven to minimize rolling resistance, enables the rider of this bike to best control, corner, and conquer.

XS S M L XL
Height (cm) 154-164 162-170 168-176 174-181 180-187
Seat Tube Length (A) 475 500 520 545 570
Seat Tube Angle (B) 74.7 74.3 74 73.7 73.3
Effective Seat Tube Angle (C) 74.7 74.3 74 73.7 73.3
Head Tube Length (D) 115 130 145 160 175
Head Tube Angle (E) 71.8 72 72.3 72.3 72.8
Effective Top Tube (F) 517.31 530.42 543.04 555.14 569.25
Bb Height (G) 271 271 271 271 271
Bb Offset (H) 73 73 73 73 73
Chainstay Length (I) 415 415 415 415 415
Wheelbase (J) 975.82 983.9 991.1 1000.62 1005.8
Frame Reach (K) 375 380 385 390 395
Frame Stack (L) 520.21 535.2 550.4 564.7 580.8
Standover Height (M) 739.4 763.21 780.8 802.52 824.28
Information
Weight 0.000 kg
Color

Black

Size

XL 700X570, M 700X520, L 700X545, S 700X500, XS 700X475, XXS 700X448

Brand

Frameset

ACX PERFORMANCE UCI APPROVED

Fork

ACX PERFORMANCE UCI APPROVED, TAPER 1-1/8" TO 1-1/2"

Shifter

SHIMANO ULTEGRA Di2 ST-R8170, 2×12-SPEED DCL

Crank

SHIMANO ULTEGRA FC-R8100 52/36T, CRANK ARM: 170mm (XS, S, M) / 172.5mm (L, XL)

Cassette

SHIMANO ULTEGRA CS-R8100-12 11-34T

Rear Derailleur

SHIMANO ULTEGRA Di2 RD-R8150 DIRECT ATTACH

BB

SHIMANO SM-BB92-41B, PRESSFIT BB86

Chain

SHIMANO CN-M8100 12-SPEED

Saddle

ENTITY FLUX2, CR-MO ø 7mm

Seatpost

CARBON, AERO 35 x 337mm (XS) / 357mm (S, M, L, XL)

Handlebar

VISION METRON 5D ACR INTEGRATED, W: 400mm (XS, S) / 420mm (M, L) / 420mm (XL), BB: INTEGRATED, R/D: 125mm, B/R: 80mm

Handlestem

VISION METRON 5D ACR INTEGRATED, EXT: 100mm (XS, S) / 110mm (M, L) / 120mm (XL), BB: INTEGRATED, R/D: 6degree

Wheel Set

ENTITY WR5 DISC (50mm) W/ TUBELESS TAPE INSTALLED

Wheel Size

700C

Tire

SCHWALBE ONE ADDIX TLE 700x28C

Rim

CARBON 622-19 24H FOR TYRE 622-28/62 DISC TUBELESS READY

Brake Lever

SHIMANO ULTEGRA HYDRAULIC DISC

Rotor

SHIMANO ULTEGRA HYDRAULIC DISC
