DOLOMIA presents the lightest frame in the MCipollini range: 780 g for size M. The geometries designed for each size also return all the responsiveness typical of MCipollini frames, together with the perfect connection of the central motion rig. Performance is further enhanced by 3K fabric that provides the best stiffness to weight ratio achievable on carbon fibre frames. The internal cable routing, thanks to the 1′ 1/2 steering series and the specific fork, guarantees maximum integration for hydraulic and electronic cabling. Overall lightness is achieved thanks to the assembly using lighter components, within the limits allowed by the UCI.
THE LIGHTER FRAME FROM MCIPOLLINI HOUSE HAS CUSTOMIZED GEOMETRIES, MAXIMUM CABLE INTEGRATION, 3K FINISH AND TCM TECHNOLOGY.
PERFORMANCE GEOMETRIES
Reactivity typical of Cipollini frames thanks to the geometries designed for each size.
INTERNAL CABLE PASSAGE
Maximum integration for hydraulic and electronic wiring thanks to the 1 ”1/2 headset and specific fork.
3K FINISH
3K fabric offers the best stiffness to weight ratio obtainable on carbon fiber frames.
TCM TECHNOLOGY
The real monocoque frame allows the perfect connection of the wagon on the bottom bracket
ASSEMBLY
Assembled with the lightest components respecting the limits allowed by the UCI.
Maximum Tire Width
29 mm (Larghezza Misurata)
Bottom Bracket
Shimano Pressfit BB92-41B PRESSFIT 41 x 86,5 mm
Seatpost
MCipollini Dolomia Offset 10mm 100 g
Headset
Conical 1.1/2” 1.1/2”
Stem
Deda Alanera(XS: 90×420 mm, S: 100×440 mm, M: 110×440 mm, L: 120×440 mm, XL: 130×460 mm e-e)
Handlebar
Deda Alanera(XS: 90×420 mm, S: 100×440 mm, M: 110×440 mm, L: 120×440 mm, XL: 130×460 mm e-e)
Rear Derailleur
Shimano Dura-Ace Di2 12s R9250
Chain
Shimano M9100 12s
Shifters
Shimano Dura-Ace Di2 R9270
Tire
Pirelli P Zero Race TLR 28
Front Derailleur
Shimano Dura-Ace Di2 R9250
Crankset
Shimano Dura-Ace R9200P 52-36 12s (XS/S: 170 mm, M/L: 172,5 mm, XL: 175 mm)
Bar Tape
Supacaz Super Sticky Kush Classic – Black, Pair
Sprocket
Shimano Dura-Ace R9200 11-34 12s
Rotors
Shimano RTCL900 160 mm
Front Wheel
Tune Schwarzbrenner 20 Skyline Disc
Rear Wheel
Tune Schwarzbrenner 20 Skyline Disc
Saddle
San Marco Shortfit Superleggera Wide
Frame
MCipollini Dolomia
Technical features
|
Wheels
|
700c | 700c | 700c | 700c | 700c |
|---|---|---|---|---|---|
|
Stack
|
507 | 524 | 539 | 560 | 585 |
|
Reach
|
367 | 377 | 384 | 397 | 403 |
|
Stack/Reach Ratio
|
1.38 | 1.39 | 1.40 | 1.41 | 1.45 |
|
Top Tube Length
|
506 | 524 | 539 | 564 | 580 |
|
Seat Tube Length
|
429 | 450 | 479 | 514 | 549 |
|
Seat Tube Angle
|
74.7 | 74.3 | 73.9 | 73.4 | 73.2 |
|
Head Tube Length
|
108 | 124 | 136 | 159 | 184 |
|
Head Tube Angle
|
70.8 | 71.4 | 72.2 | 72.7 | 73.3 |
|
BB Drop
|
71 | 71 | 71 | 69 | 68 |
|
BB Height
|
265 | 265 | 265 | 267 | 268 |
|
Front Center
|
571 | 581 | 585 | 601 | 609 |
|
Chainstay Length
|
410 | 410 | 410 | 410 | 410 |
|
Wheelbase
|
970 | 980 | 984 | 1,001 | 1,010 |
|
Rake
|
45 | 45 | 45 | 45 | 45 |
|
Trail
|
69 | 67 | 62 | 58 | 53 |
