Description
| XS | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| Rider’s height in cm | 154-164cm | 162-170cm | 168-176cm | 174-183cm | 180-187cm | 185-195cm |
| (A)Stack | 495 | 511 | 534 | 558 | 584 | 612 |
| (B) Reach | 383 | 384 | 387 | 390 | 392 | 403 |
| (C) Head Tube Angle | 72 | 72.5 | 73 | 73 | 73 | 73 |
| (D) Head Tube Length | 90 | 105 | 130 | 155 | 185 | 215 |
| (E) Seat Tube Angle | 75 | 74.5 | 74 | 73.5 | 73 | 73 |
| (F) Seat Tube Length | 454 | 474 | 500 | 525 | 554 | 584 |
| (G) Top Tube Effective | 515 | 525 | 540 | 555 | 570 | 590 |
| (H) Bottom Bracket Height | 271.5 | 271.5 | 274 | 274 | 277 | 277 |
| (I) Bottom Bracket Offset | 72.5 | 72.5 | 70 | 70 | 67.5 | 67.5 |
| (J) Chainstay | 415 | 415 | 415 | 415 | 417 | 417 |
| (K) Wheel Base | 976 | 977 | 985 | 995 | 1008 | 1028 |
| (L) Standover Height | 729 | 749 | 776 | 801 | 832 | 862 |
| Handlebar Width | 400 | 400 | 400 | 420 | 420 | 420 |
| Stem Length | 90 | 90 | 100 | 100 | 110 | 110 |
| Crank Length | 165 | 170 | 170 | 170 | 172.5 | 172.5 |
Information
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Color | Blue |
| Size | L 700X525 ,M 700X500 ,S 700X474 ,XS 700X454 ,XXS 700X439 ,XS ,S |
| Brand |
