Description
Ursus Miura TC40 Pro (Derived from Miura TC47 Specs)
1. Rim & Profile
- Material: UD‑finish full carbon fiber, tubeless-ready
- Rim Height: ~47 mm (like TC47)
- Rim Width: 28 mm outer / ~21 mm inner
- Valve Hole Diameter: ~6 mm
- Tire Compatibility: 28″ (ETRTO 24‑622), suitable for clincher or tubeless UST
2. Weight
- Front Wheel: ~780 g
- Rear Wheel: ~890 g
- Total Set: ~1,670 g
3. Spokes & Nipples
- Spokes: Straight-pull, black, Sapim CX‑Sprint (24 front/24 rear)
- Nipples: External brass with locking system, black finish
4. Hubs & Bearings
- Hubs: RD40 (or updated RD50 on some models), 24-hole, straight‑pull spoke compatible; center-lock disc brake
- Material: 7075 aluminum with “VelvetTouch” finish
- Bearings: SKF sealed ball bearings; optional CeramicSpeed upgrade
Front Axle: 100×12 mm thru‑axle - Rear Axle: 142×12 mm thru‑axle
- Freehub Compatibility: Campagnolo/SRAM/ Shimano
5. Additional Features
- Aerodynamic Profile: Based on NACA 0027 design, providing strong aero and crosswind stability
- Reflective Stickers: Rim labels use high-visibility reflective material for improved safety in low light
- Tubeless Ready: Built for UST tubeless or traditional clincher setups
🔍 Summary Table
Feature | Spec |
---|---|
Rim Height | ~47 mm (medium profile) |
Rim Width (outer/inner) | 28 mm / ~21 mm |
Weight (F/R) | 780 g / 890 g (~1,670 g total) |
Spokes / Nipples | Sapim CX‑Sprint 24/24 + brass locking nipples |
Hubs | 7075‑Alu RD40/RD50, center‑lock Disc |
Bearings | SKF sealed ball (option: CeramicSpeed) |
Axles & Freehub | 100×12 & 142×12, Shimano/Campy/SRAM |
Tires | 28″ (24‑622), clincher & tubeless ready |
Extras | Reflective decals, aero NACA 0027 profile |
Specifications
Type | Wheelsets |
Technology | Tubeless Ready |
Series | TC |
Discipline | ROAD |
Material | Carbon |
Weight (gr) | 1650 |
Compatibility | Tubeless Ready |
Information
Weight | 5 kg |
---|---|
Dimensions | 69 × 24 × 66 cm |
