Despite its smaller, lighter design, the DURA-ACE FD-R9250 brings our fastest front shifting.
Our fastest just got faster thanks to the DURA-ACE FD-R9250. Tipping the scales under 100 grams, the new design shifts 45% quicker than Shimano’s FD-R9150, already our fastest. The frontal area of the FD-R9250 is also reduced decreasing aerodynamic drag.
FEATURES
- Our fastest ever front shifting, 45% faster than FD-R9150
- Smaller, sleeker, lighter
- Frontal area reduced by 33%
- Weight cut to 96 g
- Top gear teeth capacity: 46-54T
PRODUCT SPECIFICATIONS
| MODEL NO | FD-R9250 |
|---|---|
| SERIES | DURA-ACE R9200 Series |
| Color | Series color |
| Average weight | 96 |
| Front speeds | 2 |
|---|---|
| Rear speeds | 12 |
| Compatible chain | HG 12-speed |
| Action|Down swing | ✔ |
| Mount|Brazed-on | ✔ |
| Chain line (mm) | 44.5 |
| Chainstay angle (deg.) | 61-66 |
| Top gear teeth | 46-54T |
| Total capacity | 16T |
| Link bushings | 4 |
| Firmware update by E-TUBE PROJECT | ✔ |
| SD50 port (pcs) | 0 |
| SD300 port (pcs) | 1 |
| SD50 connector (pcs) | 0 |
| SD300 connector (pcs) | 0 |
